Description

CS-Series 6×9-inch Component Speakers are built for awesome sound that plays as long as the ride takes you.

CS-Series components include titanium tweeters and two-way crossovers with a smooth 12dB slope and three-position tweeter adjustment switch (0dB/+3dB/+6dB), included in each external crossover. The optimized footprint means great sound with hassle-free installation, no matter where you mount it!

These CS speakers work best with 150 watts of recommended power. See below for more details.

Fits nearly every car made
12dB crossovers with a smaller footprint for easier installation
Three-position tweeter switch for dialing in your highs
EVC™ (Extended Voice Coil) technology help deliver remarkable bass response
Titanium tweeter construction and neodymium magnets to reveal subtle details
UV-treated poly-foam surround assists with precise linear excursion
Phase plugs in the woofer cones eliminate any distortion
Steel mesh grilles protect your drivers
Three tweeter mounting options including flush, angled and surface pods

Specifications:

Woofer Size: 6×9″ [160×230mm]

Tweeter Size: 3/4″ [20mm]

Dome Material: Titanium

Peak Power: 450 Watts

Continuous Power: 150 watts RMS

Effective Frequency Range: 30-21kHz

Woofer Mounting Hole Diameter: 5 5/8″ x 8 7/16″ [143×215mm]

Woofer Bottom Mount Depth: 3 3/16″ [81mm]

Flush Mounting Tweeter Hole Diameter: 1 9/16″ [40mm]

Flush Mount Tweeter Depth: 9/16″ [14.5mm]

High Pass | dB, at Frequency: 12, 4000 Hz

Low Pass | dB, at Frequency: 12, 4000 Hz

High Frequency Output Attenuation: 0, 3, & 6 dB

Bolt-Thru Grilles: Yes

Weight: 4Kg

Dimensions: 386 × 298 × 111 mm
